Serviceability of floor structures can be evaluated by dynamic time history analyses. Midas Gen provides Construction Stage Analysis capability, which reflects the time dependent material properties of concrete such as modulus of elasticity, creep and shrinkage. The program’s efficient analysis algorithms yield exceptional versatility and accurate results appropriate for practical design applications. A large collection of finite elements has been implemented for applications in civil and building structures. Midas Gen provides linear and nonlinear structural analysis capabilities. Data Transfer with Tekla Structure, Revit Structures is possible. Midas Gen supports conventional model generation using nodes and elements as well as other means of generating models via data conversion. Structures of regular patterns such as Truss, Arch and Frame can be readily created by Structure Wizard and inserted into the desired location on the global model. Midas Gen enables us to readily create nodes and elements as if we were drawing drawings using the majority of functions used in CAD programs.
They offer excellent facilities and productivity for the modeling and analysis of complex, large-scale structures.
The user-oriented input/output functions are based on sophisticated and intuitive User Interface and up-to-date Computer Graphics techniques. Building and General Structure Design New Standard User-friendly GUI These features contribute to higher and unprecedented standards of convenience, efficiency, versatility and productivity for structural design. midas Gen utilizes a diverse range of specialty finite element analysis functions as well as modern theories of structural analysis to render accurate and practical results. With its intuitive user interface, contemporary computer graphics and powerful solver, midas Gen enables practicing engineers to readily perform structural analysis and design for conventional and complex structures. Midas Gen Integrated Solution System for Building and General Structures
